Parker Refrigerating Specialties: 1-1/4 A4AK RV

Details

The A4A inlet family of regulators are compact, heavy duty, pilot operated, and have remarkable functionality. They sue upstream pressure for the opening force and require a minimum 0.14bar (2psig) pressure drop to open. These valves are normally ordered with close coupled upstream strainers to prevent the entrance of foreign materials into the valve and rest of system. The valve' purpose is to modulate flow of refrigerant gas or liquid to maintain constant upstream pressure as set-for, despite load fluctuations.

Features and Benefits:

• Pilot operated characterized Modulating Plug for precise control
• Suitable for all common refrigerants and oil
• 27.6bar (400psig) design pressure (MRP)
• Flanges threaded or welded steel pipe and copper tube (copper not for ammonia)
• Interchangeable parts
• Easy to service
• Close coupled strainers, optional
• Many control variations are possible with the use of a few Modules and Kits
• Stainless Steel Diaphragm
• Chrome Plated Pilot Seat Manual Opening Stem

Application:

• Depending on the specific variation of this valve, the application may include, but is not limited to;
  • Evaporator pressure control, temperature control, defrosting, Maximum Cooling, regulating defrost, Crankcase pressure regulation, Liquid Chillers, Low Pressure Drop, Hot Gas Bypass, Load Change Compensation, Reducing liquid or vapor line pressure, any inlet pressure control, Non-Atmospheric relief

More Information

Weight
27.150000

Manufacturer
Parker RS - Refrigerating Specialties

Condition
New

Port Size
1-1/4"

Pressure Range
PSI 20" Hg to 120 psig

Capacity Range
Full Capacity

Flange Size
1-1/4"

Flange Connection
Socket-Weld

Strainer Type
Without Strainer

Pressure Set Point
15 psi
