3/4 S4AE ST

Details

Parker's S4 solenoids are the refrigeration industrys standard for solenoid valves and have provided decades of safe and reliable operation. These valves are highly configurable and can be provided with flanges for Socket Welding, Butt Welding, ODS connections, and Threaded connections. The S4 is offered in sizes from 3/4" (DN20) to 8" (DN200). These valves may be opened by means of the manual opening stem for servicing or in case of electrical power failure. As the S4 valves up to 4" feature a flanged connection they may be easily removed from the system for servicing. The S4 valves are pilot operated and require a minimum 0.21 bar (3 psi) pressure drop to fully open. The S4AD is a spring closing, pilot operated, dual-position solenoid valve which is crucial for evaporator control groups that use hot gas defrost. The dual position function of the S4AD allows the system to equalize before fully opening and can prevent liquid hammer. The S4X is an explosion proof hazardous environment type solenoid carrying a NEMA Type 4 and 7 classification.

Features:

Standard Coil Housing Meets NEMA 3R and NEMA 4- Rain Tight Coil Housing Surpasses NEMA Salt Spray Test Plunger-Needle Assembly Same for S4A, S5A, S6N, S6A, S8F Molded Class "F" Coil Construction Same Coil Fits Most Refrigerating Specialties Solenoid Valves Pilot Light Available Stainless Steel Needle Manual Opening Stem Design Pressure (MRP): 28 bar (400 PSIG)

More Information

Weight
21.770000

Condition
New

Manufacturer
Parker RS - Refrigerating Specialties

Port Size
3/4"

Flange Size
No Flanges
