Parker Refrigerating Specialties: 2 RSF

Details

These industrial type Refrigerant Strainers with stainless steel screen are designed especially for the protection of R/S control valves from foreign materials present in refrigeration systems. The fine stainless screen mesh will collect particles as small as 0.009” in diameter (60 mesh @ 0.0075” wire). Generous available screen area allows maximum dirt capacity at minimum pressure drop. The strainers may be close coupled to R/S valves having the same flange gasket size.

More Information

Weight
30.130000

Manufacturer
Parker RS - Refrigerating Specialties

Condition
New

Port Size
(MM) 50mm Type RSF

Body Material
Gray Iron

Connection Style
Flange

Flange Type
No Flange

Plating
No Plating

Valve Material
Meets Pressure Equipment Directive (PED)

Flow Coefficient (CV)
68 Cv

Flow Coefficient (KV)
58 Kv Filter Screen Size 60 Mesh

Filter Screen Area (Cm2)
500

Filter Screen Area (In2)
78

Filter Screen Material
60 Mesh- Stainless Steel

Min Operating Temperature (C)
-50 °C

Min Operating Temperature (F)
-60 °F

Max Operating Temperature (C)
105 °C

Max Operating Temperature (F)
220 °F

Maximum Pressure (BAR)
27.6bar

Maximum Pressure (psig)
400psig
