Parker Refrigerating Specialties: 2 PA4CS RE 2SW 230

Details

The PA4 weld-in line series inlet pressure regulators are designed to overcome corrosion problems encountered in harsh environments.The PS4 weld-in line series solenoid valves are designed to overcome corrosion problems encountered in harsh environments. Being weld-in, these valves reduce the potential for connection leaks and can be entirely serviced from the top. The improved design has a higher working pressure, greater working temperature range and higher flow capacities than competitive products.These valves provide long-term performance and with replaceable internal components. Specially designed wear rings eliminate the need for removal of the body from the line (maintenance-free).

Features:

Optional stainless steel construction increases product life cycle Cartridge based design simplifies service and eliminates body wear Increased flow capacity enables smaller valve sizing Overall weight reduction up to 50% compared to traditional flanged products Integral features prevent contaminants from reaching the pilot section of the valve Suitable for ammonia, CO2 and halocarbon refrigerants Multiple refrigerant capacities and configurations available Interchangeable with other P-Series offerings Coil options to meet various applications

More Information

Weight
32.000000

Manufacturer
Parker RS - Refrigerating Specialties

Condition
New

Port Size
2"

Pressure Range
PSI 100 to 750 psig

Coil Type
230/50 Hz-Leaded Standard

Flange Size
2"

Flange Connection
Socket-Weld

Pressure Set Point
300 psi
