Parker Refrigerating Specialties: 2 A4AB RA 240G ST

Details

The A4A inlet family of regulators are compact, heavy duty, pilot operated, and have remarkable functionality. They sue upstream pressure for the opening force and require a minimum 0.14bar (2psig) pressure drop to open. These valves are normally ordered with close coupled upstream strainers to prevent the entrance of foreign materials into the valve and rest of system. The valve' purpose is to modulate flow of refrigerant gas or liquid to maintain constant upstream pressure as set-for, despite load fluctuations.
Features and Benefits: Pilot operated characterized Modulating Plug for precise control Suitable for all common refrigerants and oil 27.6bar (400psig) design pressure (MRP) Flanges threaded or welded steel pipe and copper tube (copper not for ammonia) Interchangeable parts Easy to service Close coupled strainers, optional Many control variations are possible with the use of a few Modules and Kits Stainless Steel Diaphragm Chrome Plated Pilot Seat Manual Opening Stem

Application:

Depending on the specific variation of this valve, the application may include, but is not limited to;  - Evaporator pressure control, temperature control, defrosting, Maximum Cooling, regulating defrost, Crankcase pressure regulation, Liquid Chillers, Low Pressure Drop, Hot Gas Bypass, Load Change Compensation, Reducing liquid or vapor line pressure, any inlet pressure control, Non-Atmospheric relief

More Information

Weight
90.230000

Manufacturer
Parker RS - Refrigerating Specialties

Condition
New

Port Size
2"

Pressure Range
PSI 5 to 150 psig

Capacity Range
Full Capacity

Coil Type
240/60 Hz-Leaded Green LED Pilot Light

Flange Size
No Flanges

Strainer Type
With Strainer

Pressure Set Point
40 psi
