1/2 SV2 240/220

Details

Parker's SV2 is a compact pilot operated solenoid valve that is ideal for liquid feed and hot gas feed applications. The valve compact size makes it ideal for installations where limited mounting space exists. The SV2 can be mounted on vertical lines which allows designers more freedom in the placement of the valve especially in tight quarters. The SV2 may be opened by means of a manual opening stem for servicing or in case of an electrical power failure. The valve can be ordered with a close couple stainless steel screen strainer. The Type SV2 valve is available with an optional extension tube to raise the solenoid operator and coil housing assembly 50mm (2.0") above the valve body to accommodate pipe Insulation. When this option is desired, the Type SV2A solenoid valve should be specified. The Type SV2 and SV2A solenoid valves can be furnished with FPT: Internal NPT (U.S. Standard Taper Pipe Thread), Socket Weld, Weld Neck, or ODS (solders over copper tubing of given diameter) connections. The valves may be easily removed from between the flanges for servicing. The SV2 is a spring closing, normally closed solenoid valve.
Features and Benefits: Strong and compact ductile iron body Pilot operated Manual opening stem Serviceable from the top Maximum Opening Pressure Differential 20.7 bar (300 psig) Design Pressure (MRP): 31.0 bar (450 psig) Pilot light available Molded Class "H" coil construction Teflon seat

Application:

Refrigerant Liquid Line
Hot Gas Line Suction Line

More Information

Weight
2.910000

Condition
New

Manufacturer
Parker RS - Refrigerating Specialties

Port Size
1/2"

Coil Type
240/60 Hz-220/50 Hz-Leaded Standard

Flange Size
No Flanges

Strainer Type
Without Strainer
