Parker Refrigerating Specialties: 1/2 SV2 120/110

Details

This compact, heavy duty, pilot operated, ductile iron bodied solenoid valve is suitable for Ammonia, R 12, R 22, R 502, and other refrigerants, certain oils and other fluids approved for use in refrigeration. This valve may be opened by means of a manual opening stem for servicing or in case of an electrical power failure. The valve can be ordered with a close couple stainless steel screen strainer.

More Information

Weight
2.920000

Condition
New

Manufacturer
Parker RS - Refrigerating Specialties

Port Size
1/2"

Port Size
(MM) 15mm

Coil Type
120AC~60Hz-110AC~50Hz-Leaded Standard

Body Material
Ductile Iron (GGG-40.3)

Flange Type
No Flange

Strainer Type
Without Strainer

Check Valve Type
No Check Valve

Valve Material
Meets Pressure Equipment Directive (PED)

Plating
No Plating

Seat Material
PTFE

Flow Coefficient (CV)
3 Cv

Flow Coefficient (KV)
2.6 Kv

Minimum Fluid Temperature(C)
-45 °C

Minimum Fluid Temperature(F)
50 °F

Maximum Fluid Temperature(C)
121 °C

Maximum Fluid Temperature(F)
250 °F

Maximum Working Temperature (F)
220 °F

Maximum Working Temperature (C)
105 °C

Maximum Rated Pressure (BAR)
31bar

Maximum Rated Pressure IG)
450psig
