Parker Refrigerating Specialties: 1/2 RSF 1/2FPT MAL

Details

These industrial type Refrigerant Strainers with stainless steel screen are designed especially for the protection of R/S control valves from foreign materials present in refrigeration systems. The fine stainless screen mesh will collect particles as small as 0.009” in diameter (60 mesh @ 0.0075” wire). Generous available screen area allows maximum dirt capacity at minimum pressure drop. The strainers may be close coupled to R/S valves having the same flange gasket size.

More Information

Weight
2.910000

Manufacturer
Parker RS - Refrigerating Specialties

Condition
New

Port Size
(MM) 15mm Type RSF

Body Material
Gray Iron

Flange Type
FPT

Plating
No Plating

Valve Material
Standard Valve

Filter Screen Material
60 Mesh- Stainless Steel

Min Operating Temperature (C)
-50 °C

Min Operating Temperature (F)
-60 °F

Max Operating Temperature (C)
105 °C

Max Operating Temperature (F)
220 °F

Maximum Pressure (BAR)
27.6bar

Maximum Pressure (psig)
400psig
